ST3C Saw spindle moulder
A$15,249.00
(Price does not include taxes, shipping and installation)
The minimax st 3c is a compact, practical and with a low investment saw spindle moulder , ideal for D.I.Y. woodworkers and craftsmen and for those who do not want to give up the reliability of SCM joinery machines.
An important feature is the presence of the scoring unit, which can be easily adjusted from the outside of the machine, as well as a surprising cut of both thick solid wood and even upgraded panels, with the saw unit with a 315mm) maximum diameter blade which guarantees a 100mm cutting height with installed scorer.
Precise and safe machining are with the spindle moulder fence with micrometric adjustment complete with vertical and horizontal pressers.
Available NO, Please contact us for ETA
Easier and more precise cutting is possible due to a perfectly stabile support that is guaranteed, even for large work pieces, but the wide sliding table and the large squaring frame fence provided as standard. Top quality precision, smooth and silent action, self-cleaning dustproof system, long lsting accuracy, no adjustment required.
An incredible cutting with the saw unit with 315mm maximum blade diameter with the scoring blade installed.
The spindle unit has a cast iron structure. It is closed off by a cast iron “cup” to protect mechanical components inside the machine from sawdust, shavings and dirt.
SCM Thundercut App for mobile devices: optimizer/sequencer even for not skilled workers.
- Extruded anodized aluminium sliding table with a closed honeycomb structure, running on an exclusive slideway system consisting of calibrated and hardened steel guides for the maximum sturdiness.
- The large squaring frame and fence (dimensions 960 x 600 mm) complete with:
telescopic fence with 2 flip-over stops, eccentric clamp and swinging arm support ensures the best performance. - Dedicated saw parallel fence complete with "high rigidity" cast iron fence support, micrometric adjustment and cam-locking system and rectified steel round sliding bar, 45 mm diameter
- Belt driven scoring unit complete with blade which can easily be adjusted from outside the machine without need of tools
- Cutting width with parallel fence 1270 mm
- Anodized aluminum tables for spindle moulder fence to ensure high rigidity
- The high effective exhaust outlet under the worktable grants a clean machine environment
- Interchangeable spindle
- 3 handwheels for the operating units movement
| Technical features |
| st 3c |
| Circular saw: |
|
|
| - cast iron saw-spindle moulder worktable dimensions | [mm] | 1115 x 430 |
| - blades tilting |
| 90° ÷ 45° |
| - max. saw blade diam. with scoring blade installed | [mm] | 315 |
| - max. saw blade projection from table at 90°/45° | [mm] | 100/78 |
| - max. squaring stroke | [mm] | 2600 |
| - cutting width on parallel fence | [mm] | 1270 |
| Spindle moulder: |
|
|
| - max. useful spindle length | [mm] | 100 |
| - spindle moulder speeds (at 50 Hz) | [rpm] | 3500/7000/10.000 |
| - max. tool diameter when profiling | [mm] | 210 |
| - max. diam. of tool lowered under the table at 90° | [mm] | 180 |
| Other technical features: |
|
|
| - single-phase motors |
| 2,2kW (3hp) 50Hz |
| - exhaust outlets diameter | [mm] | 120 |
|
|
|
|
| Spindle moulder diameter |
| 30 mm |
