minimax t 124 Wood turning lathe
A$8,033.00
(Price does not include taxes, shipping and installation)
The minimax t124 wood turning lathe contains all the features that a good lathe must have: power, speed, weight, stability and stiffness
The power must be adequate to the size of the piece being machined, this is why the minimax woodturning lathes have a power of 1,5kW and 4 speeds (570 / 1000 / 1850 / 2500 rpm) so they can machine small and large pieces.
The stability, the weight and the stiffness are three elements that are strictly linked to each other; The main characteristic is the size (width and thickness) of the woodturning lathe body and the size and weight of the legs of the base; for this reason the minimax woodturning lathe stands out from the rest thanks to its sturdiness and stability that guarantee extremely precise machining
*Photos may include optional equipment. Please verify availability and compatibility under Product Details and Specs.
Total safety for the operator thanks to the transparent guard
The copier device enables copying work at diameters greater or smaller than the template or pattern, and has a feed by hand-wheel
Copier enables copying work at diameters greater or smaller than the template of pattern. Feed by hand-wheel.
- Maximum reliability and precision, with its strong base
- The fixed steady rest reduces vibrations when turning long, thin components. The ‘C’ shape enables turning with hand tools.
- The mobile steady rest, with pre-cutting tool, guarantees a perfect finishing
- The revolving tail centre with morse taper 2 ensures that the piece is dragged without cutting it to support it.
- The flace plate, 300 mm diameter is ideal for large bowls
- Cup and screw type drive benters: 40 diameter cup centre and 70 mm screw centre from a single-piece of stainless steel. Necessary for turning small cups and bowls.
TECHNICAL FEATURES | ||
Distance between centres | mm | 1150 |
Centres height | mm | 200 |
4 chuck speeds | rpm | 570 / 1000 / 1850 / 2500 |
Tape drive with morse taper | n. | 2 N |
Ball bearing centre with morse taper | n. | 2 N |
Faceplate diameter | mm | 300 |
Single-phase motor | kW (hp) Hz | 1,5 (2) 50 |
INSTALLATION REQUIREMENTS | ||
Section of electrical cable | [mm2] | 2,5 |
Power absorption | [A] | 10 |
CE_version- voltage – frequency | 240V - 50Hz |
