l’invincibile si x Circular saw

• Additional calculation functions of the Easy Touch control panel assist the operator when designing the necessary cuts for assembled components and complex geometrical shapes
• The ± 46° tilting saw unit has a self-tensioning system of the transmission belt (SCM solution) for long-lasting performance and reliability with no compromise
• The saw blade lifting of the saw unit is carried out by a sturdy cast-iron structure with sliding on ground round slideways which guarantee the best accuracy. The unit tilting is carried out on cast-iron rotation sectors in a crescent shape to ensure reliability over time
• The saw blade uses 100% of the motor power, thanks to the scoring blade with an independent motor
• The saw unit comes with the "Pro-Lock" System for the main blade rapid locking with fast and tool-less riving knife adjustment
• Vertical and lateral adjustments of the scoring unit are carried out electronically by the "Easy Touch" control, for the maximum practicality and accuracy
• The machine is provided with a 160 mm (4.75”) diameter, manually expandable scoring blade with variable thickness from 2,8 to 3,6 mm (0.11 - 0.14”)  for the maximum versatility
• The “arc” profile of the class arch-ground steel slideways (SCM solution) ensures: no play and loads four times higher than others; +/- 0,05 mm tolerance on the entire carriage length for straight and high quality cutting; sliding effectiveness over time, thanks to the particular guides positioning which ensures protection from dust
• The carriage sliding system is guaranteed for 10 years: a proof of reliability and technology without comparisons
• The possibility to start or stop the blades motors from the pushbuttons located at the ends of the carriage considerably helps when machining large dimensioned panels
• The telescopic swinging arm that supports the support frame is the only one to be made of a large dimensioned extrusion and linear guide on recirculating ball bearings so that to ensure: maximum support, fluid movement, no play and no noise, dust protection, no need for maintenance
• Panel loading is easy on the Full Support squaring frame with an extending roller at the end. The "Quick Lock" squaring fence with rapid release SCM system minimizes set-up times granting an extremely fast fence positioning
• The telescopic "Quick Lock" squaring fence with inclined metric scale can be used to square panels measuring 3200 x 3200 mm (10.5’ x 10.5’) and has three reversible stops with electronic readouts so that they’re position can be easily read even from distance, for an absolute precision and a constant control
• The Easy Touch electronic control updates in real-time via wireless the data for the positions of the three stops, always showing the actual size of the required work piece in any cutting configuration.
• Speed and precision ensured by the motorised programmable rip fence mounted on a recirculating ball screw mechanism with sliding on linear guides. The fence can be overturned when extra-support for very large panels is needed.
• Top power! The machine has a 11kW (15hp) 60Hz motor with automatic star-delta starter
• The overhead saw blades protection automatically positions itself as a function of the blade using the exclusive "AP system" (SCM solution). This makes the transition from cuts with different angles even faster and safe, without the operator having to change the settings of the machine

*Does not include power cable
