formula feed 48 Feeder with 4 wheels and 8 speeds

A$2,081.00

(Price does not include taxes, shipping and installation)

The "formula feed 48" feeder is the best choice for safe and precise processing on each spindle moulder of all modern woodworking workshops. This feeder is equipped with 4 feeding rollers which allow to bring the piece to be machined closer to the machine tool in total safety, with precision and continuity in the feed speed, so as to ensure excellent processing.

*Photos may include optional equipment. Please verify availability and compatibility under Product Details and Specs.

Available  YES

Contact us

  • 8-speeds range to adapt to all machining needs
  • Wheels held in contact by high-stroke springs to absorb differences and defects in the workpiece, always guaranteeing maximum stability and repeatability
  • Very high rigid mobile support equipped with adjustments in all directions to adapt to any type of processing
  • Speed adjustment with simple and reliablemechanical selector
  • Wheels easy to be replaced

TECHNICAL DATA



Rollers no.



4

Feed speed

m/min

2/4/5,5/7/11/13/16,5/33

Rollers diameter

mm

120

Rollers width

mm

60

Rollers excursion

mm

18

Three-phase motors

kW (hp)

0,75 (1) 60Hz

Installation requirements



Installed motor power

[VA]

750

Voltage

[V]

400EU

Frequency

[Hz]

50
