minimax fs 30c Three-phase surfacing-thicknessing planer
A$7,367.00
(Price does not include taxes, shipping and installation)
The minimax fs 30 classic surfacing-thicknessing machine is designed for D.I.Y. woodworkers and craftsmen joineries. It has been recognized by Fine Woodworking as the "Best Overall" 12" jointer/planer in its category. This compact machine delivers premium power and precision, making it suitable for any workshop. With its long jointer tables and sturdy fence, it provides exceptional quality and durability. Manufactured in Italy, this machine offers excellent value for its price. Discover why it has become one of our best-selling units and see how it can meet your woodworking needs
*Photos may include optional equipment. Please verify availability and compatibility under Product Details and Specs.
Optimal planing
For an impeccable result, the pressure of the thicknesser feed rollers of the planer unit can be adjusted according to the type of wood machined. The thicknesser infeed roller has helical toothing to guarantee strong, constant work piece feed. In contrast, the sandblasted steel outfeed roller maintains the perfect post-machining finish.
Absolute rigidity
Very high rigidity of the surfacing fences made of extruded aluminum with 1300 mm length.
“Xylent” spiralknife cutter block with 3 series of knives
The 3 spiralknives give an exceptional finish. Reduced noise during machining provides a more comfortable working environment. It also improves the dust extraction due to the production of very small chips. Each cutter has 4 tips which can be rotated into the cutting position when worn. Therefore increasing the production life of the cutter block before knives require replacement.
1. The “Xylent” cutter block also improves the dust extraction due to the production of very small chips
2. Each cutter of the “Xylent” block has 4 tips which can be rotated into the cutting position when worn, therefore increasing the knives production life before they require replacement
3. The thicknesser infeed roller has helical toothing to guarantee strong, constant work piece feed
4. The sandblasted steel thicknesser outfeed roller maintains the perfect post-machining finish.
MACHINE CONFIGURATION
(Options and accessories included with this machine)
- minimax fs 30c CE version
- "Xylent" spiralknife cutterblock with 3 series of knives
| TECHNICAL DATA | ||
| Cutterhead working width | mm | 300 |
| XYLENT Spiral helical Cutterhead: Cutterblock diameter / no° of standard knives Dimension of standard knives | mm / n° mm | 72 / 48 15 x 15 x 2.5 |
| Max. stock removal | mm | 4 |
| Jointer table length | mm | 1510 |
| Planer table dimensions | mm | 300 x 585 |
| Planer feed speed | m/min | 7 |
| Min. - max. planer working height | mm | 3 - 230 |
| Fence Tilt | degrees | 0 - 45 |
| Three Phase Motor | kW/Hp | 4/5.5 |
Installation data
section of electrical cable [mm2] 6
power absorption [A] 20
voltage - frequency 400V - 50Hz
