nova s 520 Thicknessing planer - Tersa

The Tersa cutterblock with automatic knives clamping by means of the centrifugal force ensures safe and precise machining. The system, without fixing screws, makes knives substitution extremely fast.

The stopping of the work piece and the presence of notches on its surface are eliminated due to the movement system on connecting rods of all the three feeding rollers that allows their vertical displacement by rotation so to have the best linear feeding.

The 4 dust protected screws with a large diameter combined with the 2 side linear guides ensure worktable sturdiness and stability, eliminating the necessity of  locking it in position and guaranteeing high precision and reliability over time.

Quick and easy changeover of the rollers thanks to their interchangeable system that allows the operator to configure the machine drive function in case of special requirements such as minimum removals of fine woods.

Perfect finish with the feeding rollers on connecting roads. The stopping of the work piece and the presence of notches on its surface are eliminated due to the movement system on all three rollers that allows their vertical displacement by rotation and the best linear feeding.

Sturdy structure with precision when moving the work table

The 4 screws with a large diameter combined with the 2 side linear guides ensure worktable stability eliminating the necessity of  locking in position. The integrated protections guarantee high precision and reliability over time.

Exceptional finish with the “Xylent” spiral knife (3 spiral knives) Reduced noise during machining provides a more comfortable working environment. It also improves the dust extraction due to the production of very small chips. Each cutter has 4 tips which can be rotated into the cutting position when worn. Therefore increasing the production life of the cutter block before knives require replacement.
