class ti 120 Spindle moulder
$15,985.00
(Price does not include taxes, shipping and installation)
The class ti120 spindle moulder is the best solution for every application. In fact the set up precision and reliability is guaranteed to the operator that can easily adjusts all movements due to the hand wheels with mechanical decimal readouts located on the front of the machine. Another aspect that adds ease of use and speed to the machine, is the spindle moulder fence with mechanical programming. No more test runs due to digital readouts that ensure accuracy to a tenth of a millimetre in positioning the two tables.
*Photos may include optional equipment. Please verify availability and compatibility under Product Details and Specs.
The operator easily adjusts all movements due to the hand wheels with mechanical decimal readouts located on the front of the machine for a precise and reliable machine’s set up.
The spindle moulder fence with mechanical programming and digital readouts ensures accuracy to a tenth of a millimetre in positioning the tables so that no more test runs are required to get the desired result.
- Maximum stability and rigidity in all working conditions, thanks to a large spindle moulder column made entirely of cast iron
- The shaper spindle is surrounded by a cast iron “cup” to protect the internal mechanical components from shavings and sawdust
- The 5 standard speeds of the shaper are ideal for any type of machining, from shaping to routing to tenoning, with the possibility to fit tools up to 250 mm of diameter
- The shaper has a tiltable spindle moulder -45° ÷ +45° for the maximum versatility
- The side handles make it easy to remove and reposition the spindle moulder fence from the worktable
- The carriage on the worktable, with easy fitting and removal system when needed, is ideal for tenoning of small work-pieces and to perform mitre cuts with angles of ± 60°
- Top power! The machine has a 8kW (11hp) 60Hz motor with automatic star-delta starter
*Do not include power cable
MACHINE CONFIGURATION
(Options and accessories included with this machine)
- Spindle moulder fence with mechanical adjustment
- Aluminium fence instead of wooden fence
- 7kW 50Hz (8kW 60Hz) motor power
- Carriage on fixed table for small tenoning operations
- MK4 interchangeable spindle
- Spindle moulder shaft of 1 1/4"
- Locking by countersunk socket screw
- Locking without slot
| TECHNICAL FEATURES | ||
| Spindle moulder diameter | mm(in) | 1 1/4" |
| Max. useful spindle length | mm(in) | 180 (7.06”) |
| Spindle tilting | rpm | -45° ÷ +45° |
| Spindle moulder speeds | mm(in) | 3000/4500/6000/7000/10.000 |
| Max. tool diameter when profiling | mm(in) | 250 (9.81”) |
| Max. diam. of tool lowered under the table at 90° | mm(in) | 320 (12.62”) |
| Max. tool diameter when tenoning | mm(in) | 250 (9.81”) |
| Other technical features: | ||
| Three-phase motor | 8kW (11hp) 60Hz | |
| Exhaust outlets diameter | 120 (4.75”) | |
| MINIMUM INSTALLATION REQUIREMENTS | ||
| Power absorption | A | 26 |
| Voltage frequency | 230V - 60Hz |
